CHASSIS 5-53
BRAKE CALIPER REMOVAL AND
DISASSEMBLY
• Remove the brake hose union bolt 1 and allow the brake fluid
to drain into a suitable receptacle.
• Remove the brake caliper mounting bolts 2 and rear torque
link nut 3.
NOTE:
Slightly loosen the brake caliper housing bolts
4
to facilitate later
disassembly before removing the brake caliper mounting bolts.
#
Never reuse the brake fluid left over from previous
servicing and which has been stored for long periods of
time.
'
Brake fluid, if it leaks, will interfere with safe running and
discolor painted surfaces. Check the brake hose and
hose joints for cracks and oil leakage.
• Remove the brake pads. (! 5-52)
• Remove the brake caliper housing bolts 5.
• Separate the brake caliper halves.
• Remove the O-ring 6.
#
Replace the O-ring with a new one.
To Next Page
