5-12 CHASSIS
Front fork protecter
Dust seal
Oil seal stopper ring
Oil seal
Oil seal retainer
Outer tube slide metal
Oil lock piece
Outer tube (R)
Outer tube (L)
Gasket
Ring
Cylinder
Spring
Inner tube
Inner tube slide metal
O-ring
Spacer
Washer
Spring
Front fork cap bolt
Front axle pinch bolt
Cylinder bolt
FRONT FORK
CONSTRUCTION
"
ITEM N
.
m kgf
.
m lb-ft
A 23 2.3 16.5
B 23 2.3 16.5
C 30 3.0 21.5
