5-22 CHASSIS
• Remove the ignition switch 6 using a Torx wrench.
% 09930-11920: Torx bit
09930-11940: Bit holder
INSPECTION AND DISASSEMBLY
Inspect the removed parts for the following abnormalities.
*Handlebar distortion
*Race wear or damage
*Bearing wear or damage
*Abnormal bearing noise
*Distortion of the steering stem
• Remove the steering stem lower bearing inner race using a
chisel.
#
The removed bearing inner race should be replaced with
a new one.
• Remove the steering stem upper and lower bearing races
using the special tools.
% 09941-54911: Bearing outer race remover
09941-74911: Steering bearing installer
REASSEMBLY AND REMOUNTING
Reassemble and remount the steering stem in the reverse order
of removal and disassembly. Pay attention to the following points.
OUTER RACES
• Press in the upper and lower outer races using the special tool.
% 09941-34513: Steering outer race installer
