CHASSIS 5-29
INSPECTION AND DISASSEMBLY
TIRE ............................................................. (! 5-58)
REAR WHEEL ............................................. (! 5-9)
WHEEL BEARING ...................................... (! 5-9)
(Use the front wheel specifications and procedure.)
REAR SPROCKET MOUNTING DRUM BEARING
Inspect the play of the bearing by hand while it is in the rear
sprocket mounting drum.
Rotate the inner race by hand to inspect it for abnormal noise
and smooth rotation. Replace the bearing if there is anything
unusual.
• Remove the rear sprocket mounting drum dust seal using the
special tool.
% 09913-50121: Oil seal remover
• Remove the bearings using the special tool.
% 09921-20220: Bearing remover set
#
The removed dust seal and bearing must be replaced
with new ones.
Play
Play
