2-22 PERIODIC MAINTENANCE
Check that all chassis bolts and nuts are tightened to their specified torque. (Refer to page 2-23 for the
locations of the following nuts and bolts.)
ITEM N
.
m kgf
.
m lb-ft
1 Steering stem head nut 65 6.5 47.0
2 Front fork upper pinch bolt 23 2.3 16.5
3 Front fork lower pinch bolt 23 2.3 16.5
4 Front fork cap bolt 23 2.3 16.5
5 Front axle 65 6.5 47.0
6 Front axle pinch bolt 23 2.3 16.5
7 Handlebar holder bolt 23 2.3 16.5
8 Front brake master cylinder clamp bolt 10 1.0 7.0
9 Front brake caliper mounting bolt 39 3.9 28.0
0 Brake hose union bolt (front & rear) 23 2.3 16.5
A Air bleeder valve (front & rear) 8 0.8 6.0
B Brake disc bolt (front & rear) 23 2.3 16.5
C Rear brake caliper mounting bolt 25 2.5 18.0
D Rear brake caliper housing bolt 30 3.0 21.5
E Rear brake master cylinder mounting bolt 23 2.3 16.5
F Rear brake master cylinder rod locknut 18 1.8 13.0
G Front footrest bolt 39 3.9 28.0
H Front footrest bracket bolt 23 2.3 16.5
I Swingarm pivot nut 100 10.0 72.5
J Rear shock absorber mounting nut (upper & lower) 50 5.0 36.0
K Cushion lever mounting nut 78 7.8 56.5
L Cushion lever rod mounting nut 78 7.8 56.5
M Rear axle nut 100 10.0 72.5
N Rear sprocket nut 50 5.0 36.0
O Rear torque link nut (front & rear) 35 3.5 25.5
CHASSIS BOLTS AND NUTS
Tighten initially at 1 000 km (600 miles, 1 month) and ev-
ery 6 000 km (4 000 miles, 12 months) thereafter.
To Next Page
