CHASSIS
5-3
REMO
V
AL
CO
WLING AND CO
WLING BRA
CE (Except for GSF600)
•
Remov
e the two screws
.
•
Remov
e the rear view mirrors
1
and the front cowling
2
.
Hooked par
t
•
Remov
e the side cowling
4
(left and right).
•
Disconnect the tur
n signal lead wire coupler
.
•
Remov
e the center cowling
3
.
•
Remov
e the screen
5
.
Hooked par
t
166
168
