5-56 CHASSIS
• Remove the brake hose connector by removing the screw.
• Remove the O-ring 1.
#
Replace the O-ring with a new one.
• Pull the dust boot 2 out and remove the circlip 3.
% 09900-06108: Snap ring pliers
• Remove the push rod 4, piston/primary cup 5 and spring 6.
MASTER CYLINDER INSPECTION
MASTER CYLINDER
Inspect the master cylinder bore for any scratches or other
damage.
PISTON
Inspect the piston surface for any scratches or other damage.
RUBBER PARTS
Inspect the primary/secondary cup and all of the rubber parts for
damage.
