6-20 ELECTRICAL SYSTEM
TROUBLE SHOOTING
No click
Runs
The transmission is in neutral. Grasp the
clutch lever. Turn on the ignition switch with
the engine stop switch in the “RUN" position.
Listen for a click from the starter relay when
the starter button is pushed.
Clicks
No Voltage
Engine does not turn though the
starter motor runs.
Faulty starter relay
Loose or disconnected starter
motor lead wire
Faulty ignition switch
Faulty engine stop switch
Open circuit in wire harness
Measure the starter relay voltage at the
starter relay connectors (between B/Y
and B/W
) when the starter button is
pushed.
Faulty clutch lever position
switch
No good
Voltage
Faulty gear position switch
Check the starter relay.
(
6-23)
OK
Others
Faulty side-stand switch
Check the side-stand switch.
(
6-25)
Check if the starter motor runs
when its terminal is connected to
the battery
terminal (Do not use
a thin “wire” because a large
amount of current flows.)
Starter motor will not run.
Faulty starter motor
Dose not run
Faulty turn signal/side-stand
relay
Faulty starter button
Poor contact of connector
Open circuit in wire harness
Faulty starter relay
Poor contact of the starter relay
OK
The starter motor runs when the transmission is in neutral, but does not run when the transmission is
in any position other than neutral, with the side-stand up.
No good
Poor contact of connector
Faulty side-stand switch
To Next Page
