AFG3000 Series Arbitrary/Function Generators Service Manual 5-1
Adjustment Procedures
This section describes the procedures necessary to manually adjust the AFG3000
Series Arbitrary/Function Generators. Execute each adjustment when you
exchange a circuit board.
Purpose
This procedure returns the arbitrary/function generator to compliance with its
Warranted Characteristics as listed in the Specification section. It can also be used
to optimize the performance of the arbitrary/function generator.
Adjustment Interval
Generally, these adjustments should be done every 12 months.
Adjustment After Repair
After the removal and replacement of a module due to electrical failure, perform
the adjustment procedure in this section. The table below lists the adjustment items
that should be performed after repair.
Table 5-1: Adjustments performed after repair
Adjustment AFG3011 AFG3021B, AFG3022B AFG3101, AFG3102, AFG3251, AFG3252
A72 CPU A43
Generator
A72 CPU A11, A12
Generator
A72 CPU A31, A32, A41,
A42 Generator
A51, A61 Output
Reference ClockXXXXX X
LF X X X X X
Flatness XXXXX X X
Spurious X X X
Trigger Delay XXXXX X
