Tektronix AFG3102 Service Manual

Specifications
1-4 AFG3000 Series Arbitrary/Function Generators Service Manual
Table 1-4: Phase (except DC, Noise, and Pulse)
Characteristics Description
Range
1
–180.00° to +180.00°
1. Resolution: 0.01° (sine), 0.1° (other standard waveforms)
Table 1-5: Lead delay (pulse)
Characteristics Description
Range
Continuous mode 0 ps to period
Triggered/Gated Burst mode 0 ps to period – [pulse width + 0.8 * (leading edge time + trailing edge time)]
Resolution 10 ps or 8 digits
Table 1-6: Amplitude
Characteristics Description PV reference
page
Range
1
AFG3011 20 mV
p-p
to 20 V
p-p
40 mV
p-p
to 40 V
p-p
(into open circuit load)
AFG3021B, AFG3022B 10 mV
p-p
to 10 V
p-p
20 mV
p-p
to 20 V
p-p
(into open circuit load)
AFG3101, AFG3102 20 mV
p-p
to 10 V
p-p
40 mV
p-p
to 20 V
p-p
(into open circuit load)
AFG3251, AFG3252 50 mV
p-p
to 5 V
p-p
100 mV
p-p
to 10 V
p-p
(into open circuit load)
✔Accuracy page 4-21
AFG3011 ±(2% of setting +2 mV) (amplitude ≤ 10 V
p-p
)
±(2% of setting +2 mV) (typical) (amplitude > 10 V
p-p
)
AFG3021B, AFG3022B,
AFG3101, AFG3102,
AFG3251, AFG3252
±(1% of setting +1 mV) (at 1 kHz sine waveform, amplitude > 10 mV
p-p
, 0 V offset)
Resolution 0.1 mV
p-p
, 0.1 mV
rms
, 1 mV, 0.1 dBm or 4 digits
Units
2
V
p-p
, V
rms
, dBm, and Volt (High level and Low level)
Output impedance 50 Ω
Isolation 42 V
pk
maximum to earth
1. AFG3251/AFG3252 (frequency range: >200 MHz to 240 MHz): 50 mV
p-p
to 4 V
p-p
into 50 Ω, 100 mV
p-p
to 8 V
p-p
into open circuit load
2. dBm is used only for sine waveform.
