Tektronix AFG3102 Service Manual

Specifications
AFG3000 Series Arbitrary/Function Generators Service Manual 1-9
Jitter (rms), typical
AFG3021B, AFG3022B
AFG3011
4 ns
AFG3101, AFG3102 1 ns at 1 GS/s
4 ns at 250 MS/s
AFG3251, AFG3252 500 ps at 2 GS/s
4 ns at 250 MS/s
1. Exclude harmonics and channel crosstalk.
Table 1-9: Output characteristics (cont.)
Characteristics Description PV reference
page
Table 1-10: Modulation
Characteristics Description
AM (Amplitude Modulation)
Carrier waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arb
1
Internal modulating
frequency
2 mHz to 50.00 kHz
Depth
0.0% to 120.0%
FM (Frequency Modulation)
Carrier waveforms Standard waveforms (except Pulse, DC, and Noise) and Arb
Modulation source Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arb
2
Internal modulating
frequency
2 mHz to 50.00 kHz
Peak deviation
AFG3011 DC to 5 MHz
AFG3021B, AFG3022B DC to 12.5 MHz
AFG3101, AFG3102 DC to 50 MHz
AFG3251, AFG3252 DC to 120 MHz
