Troubleshooting
AFG3000 Series Arbitrary/Function Generators Service Manual 6-29
Calibration
This procedure uses internal routines to verify that the instrument is operating
correctly.
Do the following steps to run the internal routines that confirm basic functionality
and proper adjustment:
1. Select the Diagnostics item in the Utility menu.
Utility (front panel) > -more- (bezel) > Diagnostics/Calibration > Execute
Calibration
2. Wait until the test is completed.
3. Verify passing of the calibration.
If the calibration completes without any problems, the message “PASSED” is
displayed.
When an error is detected during calibration execution, the instrument displays
an error code. Error codes are described in Error Codes on page 6-30.
4. Press any front panel button to exit from the diagnostics.
Equipment required None
Prerequisites
Power on the instrument and allow a 20 minute warm-up before
doing this procedure.
An ambient temperature is between +20 °C and +30 °C.
NOTE. Do not turn off the power while executing calibration. If the power is turned
off while calibration, data stored in internal nonvolatile memory may be lost.
