Adjustment Procedures
5-12 AFG3000 Series Arbitrary/Function Generators Service Manual
Setting the Serial Number
When you replace the A72 CPU board, you must set the serial number. Perform the
following procedure to set the serial number:
1. Enable the service mode. Refer to page 5-3.
2. Push the Utility > -more- > -more- buttons.
3. Push the Service Menu > Factory Initialize > Serial Number buttons.
4. Enter the serial number with numeric keys and Function buttons.
Setting the MAC Address
MAC Address has already been set, and need not usually be set. When a new MAC
address setup is required, perform the following procedure:
1. Enable the service mode. Refer to page 5-3.
2. Push the Utility > -more- > -more- buttons.
3. Push the Service Menu > Factory Initialize > MAC Address buttons.
4. Enter the MAC address with numeric keys and Function buttons.
5. Push the OK button.
NOTE. Use the Function buttons to enter alphabetical characters. The Sine to
More... button corresponds to A through F.
NOTE. Use the Function buttons to enter alphabetical characters. The Sine to
More... button corresponds to A through F.
Use the +/– key to enter the hyphen.
