AFG3000 Series Arbitrary/Function Generators Service Manual 3-1
Theory of Operation
This section describes the electrical operation of the AFG3000 Series
Arbitrary/Function Generators to the module level. It describes the basic operation
of each functional circuit block shown in Figure 3-1. The descriptions for the one
and two channel units, and the color and monochrome units are slightly different.
Overview
AFG3000 Series Arbitrary/Function Generators provide seven models with
different frequency and number of channels. Each model consists of two major
sections: the platform section and the generator section. The platform section is
common to each model.
The combination of circuit boards in each model is shown in Table 3-1.
Table 3-1: Combination of circuit boards used in each model
Circuit board AFG3021B AFG3022B AFG3101 AFG3102 AFG3251 AFG3252 AFG3011
A11 Generator with Amp 1ch 1
A12 Generator with Amp 2ch 1
A31 Generator 1ch 1
A32 Generator 2ch 1
A41 Generator High 1ch 1
A42 Generator High 2ch 1
A43 Generator 1
A51 Output Amp 1 2
A61 Output Amp 1 2
A72 CPU 1111111
A75 Front Panel 1111111
A80 BNC/Peltola 11212
A81 Front BNC Insulator 1111111
A82 Rear BNC Insulator 1111111
