Maintenance
AFG3000 Series Arbitrary/Function Generators Service Manual 6-3
Inspection and Cleaning
procedures
The collection of dirt on internal components can cause them to overheat and fail.
Dirt also provides an electrical conduction path
that could cause an
arbitrary/function generator failure, especially under high-humidity conditions.
Inspect the arbitrary/function generator as often as operating conditions require.
Exterior Inspection. Inspect the outside of the arbitrary/function generator for
damage, wear, and missing parts, using Table 6-1 as a guide. Arbitrary/function
generator that appears to have been dropped or otherwise abused should be
checked thoroughly to verify correct operation and performance. Immediately
repair defects that could cause personal injury or cause further arbitrary/function
generator.
Exterior Cleaning Procedure. Do the following steps to clean the arbitrary/function
generator exterior:
1. Remove loose dust on the outside of the arbitrary/function generator with a
lint-free cloth. Use care to avoid scratching the clear glass display shield.
2. Remove remaining dirt with a lint free cloth dampened in a general purpose
detergent-and-water solution. Do not use abrasive cleaners.
CAUTION. Avoid the use of chemical cleaning agents which might damage the
plastics used in this AFG3000 Series arbitrary/function generator. Use only
deionized water when cleaning the front-panel buttons. Use an ethyl alcohol
solution as a cleaner and rinse with deionized water.
Table 6-1: External inspection check list
Item Inspect for Repair action
Cabinet, front panel, and cover Cracks, scratches,
deformations, damaged
hardware or gaskets.
Repair or replace defective
module.
Front-panel knobs Missing, damaged, or loose
knobs.
Repair or replace missing or
defective knobs.
Connectors Broken shells, cracked
insulation, and deformed
contacts. Dirt in connectors.
Repair or replace defective
modules. Clear or wash out
dirt.
Carrying handle, bail, cabinet
feet
Correct operation. Repair or replace defective
module.
CAUTION. To prevent getting moisture inside the arbitrary/function generator
during external cleaning, use only enough liquid to dampen the cloth or applicator.
To avoid damage to the surface of the arbitrary/function generator, do not use any
abrasive or chemical cleaning agents.
