Tektronix AFG3102 Service Manual

Performance Verification
AFG3000 Series Arbitrary/Function Generators Service Manual 4-5
Test Record
Photocopy this test record and use to record the performance test results for your
AFG3000 Series Arbitrary/Function Generators. Excel spreadsheet Test record
with embedded calculation formulas is also available in standard accessory
document CD P/N 063-3828-xx.
AFG3000 Series Performance
Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
AFG3000 Series Performance Test Record
Minimum
Test result Maximum
Frequency
Sine at 1.000000 MHz 0.999999 MHz 1.000001 MHz
Pulse at 1.000000 MHz 0.999999 MHz 1.000001 MHz
Amplitude
AFG3011 CF = 2 / (1 + 50 Ω / Measurement Ω) =
CH1Amplitude
30.0 mVrms at 1.00 kHz (30.0 × CF – 1.307) mVrms (30.0 × CF + 1.307) mVrms
300.0 mVrms at 1.00 kHz (300.0 × CF – 6.71) mVrms (300.0× CF + 6.71) mVrms
800.0 mVrms at 1.00 kHz (800.0 × CF – 16.71) mVrms (800.0 × CF + 16.71) mVrms
1.500 Vrms at 1.00 kHz (1.500 × CF – 0.0307) Vrms (1.500 × CF + 0.0307) Vrms
2.000 Vrms at 1.00 kHz (2.000 × CF – 0.0407) Vrms (2.000 × CF + 0.0407) Vrms
2.500 Vrms at 1.00 kHz (2.500 × CF – 0.0507) Vrms (2.500 × CF + 0.0507) Vrms
3.500 Vrms at 1.00 kHz (3.500 × CF – 0.0707 Vrms (3.500 × CF + 0.0707) Vrms
