Specifications
AFG3000 Series Arbitrary/Function Generators Service Manual 1-11
Inputs/Outputs
Table 1-11: Front panel
Characteristics Description
Trigger output
Level Positive TTL level pulse into 1 kΩ
Impedance 50 Ω
Jitter (rms), typical
AFG3021B, AFG3022B,
AFG3011
500 ps
AFG3101, AFG3102 200 ps
AFG3251, AFG3252 100 ps
Trigger input
Level TTL compatible
Pulse width 100 ns minimum
Impedance 10 kΩ
Slope Positive/negative, selectable
Trigger delay 0.0 ns to 85.000 s
Resolution: 100 ps or 5 digits
Jitter (rms), typical Burst: < 500 ps (trigger input to signal output)
