Performance Verification

4-22 AFG3000 Series Arbitrary/Function Generators Service Manual

4. Set up the arbitrary/function generator using the following steps:

5. Verify that each amplitude measurement is within the range specified in the

following tables.

Select menu Setting Operation

Function Sine Sine (front)

Frequency 1.000000 kHz Frequency/Period (front)

Amplitude Units V rms

The voltage unit should be

matched to that of DMM.

Top Menu > Amplitude/Level Menu > -more-

> Units > V rms

Amplitude 0.030 Vrms Amplitude/High (front)

Channel 1 Output On On (front)

AFG3011 Measurement Range

Function Frequency Amplitude

Sine 1.000 kHz 30.0 mVrms mVrms (30.0 × CF ± 1.307) mVrms

Sine 1.000 kHz 300.0 mVrms mVrms (300.0 × CF ± 6.71) mVrms

Sine 1.000 kHz 800.0 mVrms mVrms (800.0 × CF ± 16.71) mVrms

Sine 1.000 kHz 1.500 Vrms Vrms (1.500 × CF ± 0.0307) Vrms

Sine 1.000 kHz 2.000 Vrms Vrms (2.000 × CF ± 0.0407) Vrms

Sine 1.000 kHz 2.500 Vrms Vrms (2.500 × CF ± 0.0507) Vrms

Sine 1.000 kHz 3.500 Vrms Vrms (3.500 × CF ± 0.0707) Vrms

AFG302xB and AFG310x Measurement Range

Function Frequency Amplitude

Sine 1.000 kHz 30.0 mVrms mVrms (30.0 × CF ± 0.654) mVrms

Sine 1.000 kHz 300.0 mVrms mVrms (300.0 × CF ± 3.35) mVrms

Sine 1.000 kHz 800.0 mVrms mVrms (800.0 × CF ± 8.35) mVrms

Sine 1.000 kHz 1.500 Vrms Vrms (1.500 × CF ± 0.0154) Vrms

Sine 1.000 kHz 2.000 Vrms Vrms (2.000 × CF ± 0.0204) Vrms

Sine 1.000 kHz 2.500 Vrms Vrms (2.500 × CF ± 0.0254) Vrms

Sine 1.000 kHz 3.500 Vrms Vrms (3.500 × CF ± 0.0354) Vrms
