Performance Verification

4-36 AFG3000 Series Arbitrary/Function Generators Service Manual

4. Verify that the rise/fall time of the square waveform on the oscilloscope at each

amplitude is equal to or less than the limit specified in the following tables. Use

–90% reference level for rise/fall time measurement.

5. (AFG3xx2 only) Repeat steps 2 through 4 for the channel 2 output.

AFG3011 Oscilloscope Measurement

Function Frequency Offset Amplitude Vertical Horizontal Limit

Square 2.00 MHz 0.0 V 1.0 V

200 mV/div 20 ns/div or

25 ns/div

≤ 50 ns

Square 2.00 MHz 0.0 V 10.0 V

200 mV/div

with x10 attenuator

20 ns/div or

25 ns/div

≤ 50 ns

AFG302xB Oscilloscope Measurement

Function Frequency Offset Amplitude Vertical Horizontal Limit

Square 10.00 MHz 0.0 V 1.0 V

200 mV/div 5 ns/div ≤ 18 ns

Square 10.00 MHz 0.0 V 10.0 V

200 mV/div

with x10 attenuator

5 ns/div ≤ 18 ns

AFG310x Oscilloscope Measurement

Function Frequency Offset Amplitude Vertical Horizontal Limit

Square 10.00 MHz 0.0 V 1.0 V

200 mV/div 2 ns/div ≤ 5 ns

Square 10.00 MHz 0.0 V 10.0 V

200 mV/div

with x10 attenuator

2 ns/div ≤ 5 ns

AFG325x Oscilloscope Measurement

Function Frequency Offset Amplitude Vertical Horizontal Limit

Square 10.00 MHz 0.0 V 1.0 V

200 mV/div 1 ns/div ≤ 2.5 ns

Square 10.00 MHz 0.0 V 5.0 V

1.0 V/div 1 ns/div ≤ 2.5 ns
