Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
c. Modify the init
ialized front-panel control settings:
Readjust the Trigger Level knob so the trigger level is at 50% of the
rising edge of
the sine wave.
From the button bar, touch the Horiz/Acq button. Select the Manual
buttontotu
rn on Manual Mode.
Select the Acquisition tab. Press the IT button to turn on Interpolate
Time Only .
From the button bar, touch the Vertical button.
Select Analog Only.
Set the vertical scale, record length, and sample rate as indicated in
the following table.
Table 3-11: Delta time measurement settings
Instrument Volts/div
Sine wave
generator
frequency
Record
length
Sample
rate
Burst
width
Delta time rms
accuracy limit
Delta time
pk-pk
accuracy limit
BWE off
10 mV
9.94 GHz
10000
500 GS/s
10 ns 1.280 ps 12.80 ps
50 mV
9.94 GHz
10000
500 GS/s
10 ns 1.172 ps 11.72 ps
MSO72004C and
DPO72004C, BWE
off
100 mV
9.94 GHz
10000
500 GS/s
10 ns 1.186 ps 11.86 ps
10 mV
9.94 GHz
10000
500 GS/s
10 ns 1.280 ps 12.80 ps
50 mV
9.94 GHz
10000
500 GS/s
10 ns 1.172 ps 11.72 ps
MSO71604C and
DPO71604C, BWE
off
100 mV
9.94 GHz
10000
500 GS/s
10 ns 1.186 ps 11.86 ps
10 mV
7.76 GHz
10000
500 GS/s
10 ns 1.304 ps 13.04 ps
50 mV
7.76 GHz
10000
500 GS/s
10 ns 1.201 ps 12.01 ps
MSO71254C and
DPO71254C, BWE
off
100 mV
7.76 GHz
10000
500 GS/s
10 ns 1.205 ps 12.05 ps
10 mV
4.97 GHz
10000
500 GS/s
10 ns 1.462 ps 14.62 ps
50 mV
4.97 GHz
10000
500 GS/s
10 ns 1.295 ps 12.95 ps
MSO70804 and
DPO70804B, BWE
off
100 mV
4.97 GHz
10000
500 GS/s
10 ns 1.336 ps 13.36 ps
10 mV
3.73 GHz
10000
500 GS/s
10 ns 1.625 ps 16.25 ps
50 mV
3.73 GHz
10000
500 GS/s
10 ns 1.427 ps 14.27 ps
MSO70604 and
DPO70604B, BWE
off
100 mV
3.73 GHz
10000
500 GS/s
10 ns 1.463 ps 14.63 ps
10 mV
2.48 GHz
10000
500 GS/s
10 ns 2.022 ps 20.22 ps
50 mV
2.48 GHz
10000
500 GS/s
10 ns 1.762 ps 17.62 ps
MSO70404 and
DPO70404B, BWE
off
100 mV
2.48 GHz
10000
500 GS/s
10 ns 1.821 ps 18.21 ps
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 3–81
