Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-6: Input/output port specifications, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Characteristic Description
Input and output ports
Scope XGA Video port,
DSA70000B, DPO70000B,
and DPO7000 models
15 pin D-sub female connector
VGA Video output port,
DSA70000B, DPO70000B,
and DPO7000 models
15 pin D-Sub female connector
DVI-I Video port,
MSO70000/C and
DSA/DPO70000C models
A female Digital Visual Interface (DVI-I) compatible port
Parallel port (IEEE 1284),
DSA/DPO70000B and
DPO7000 models
25 pin D-Sub connector, supports the following modes:
standard (output only)
bidirectional (PS-2 compatible)
bidirectional enhanced parallel port (IEEE 1284 standard, mode 1 or mode 2, v 1.7)
bidirectional high-speed extended capabilities port (ECP)
Passive eSATA Port,
MSO70000/C and
DSA/DPO70000C models
Instrument must be powered down to make connection
Serial port,
DSA/DPO70000B, and
DPO7000 models
9 pin D-Sub COM1 port, uses NS16C550-compatible UARTS, transfer speeds up to 115.2 kb/s
COM1 and COM2 serial
ports, MSO70000/C and
DSA/DPO70000C models
9 pin D-Sub ports, use NS16C550-compatible UARTS, transfer speeds up to 115.2 kb/s
Keyboard and Mouse ports
PS-2 compatible, instrument must be powered down to make connection
LAN port
RJ-45 connector, supports 10 base-T, 100 base-T, and Gigabit Ethernet
External audio ports
External audio jacks for microphone input and line output
USB ports Four side or rear panel and 1 front panel USB 2.0 connectors
GPIB port IEEE 488.2 standard interface, listener or controller
MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series 1–55
