Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-4: Seri
al Trigger specifications, all MSO70000/C and DSA/DPO70000B/C Series models (optional on
DPO7000 models)
Characteristic Description
Low speed serial trigger,
≥ 4 GHz models
Number of bits
128 bits
Baud rate limits
10 Mbits/s
High speed serial trigger
number of bits
≥ 4 GHz models 64 bits for NRZ data rates ≤ 1.25 GBaud
40 bits for 8b/10b data rates between 1.25 GBd and 6.25 GBd
< 4 GHz models
64 bits
High speed serial trigger,
serial word recognizer
position accuracy
≥ 4 GHz models
± 200 ps
Acquisition mode
Sample, Average ± (1 waveform interval + 200 ps)
< 4 GHz models
Peak Detect, Envelope
± (2 waveform intervals + 200 ps)
Serial trigger decoding
types
≥ 4 GHz models ≤ 1.25 GB:
1.25 GB to 6.25 GB:
NRZ
8B10B
< 4 GHz models
NRZ
Serial trigger baud rate
limits
≥ 4 GHz models, typical Up to 1.25 GBd, NRZ
NRZ 8B10B encoded data at the following bit rates
1.25 GBd,
1.50 GBd,
1.57 GBd,
2.00 GBd,
2.125 GBd,
2.50 GBd,
3.00 GBd,
3.125 GBd,
4.25 GBd,
4.80 GBd,
5.00 GBd,
6.00 GBd,
6.25 GBd
< 4 GHz m odels Up to 1.25 GBd (Option PTM adds protocol trigger to DPO7000 Series)
Error detection jitter
tolerance
≤ 0.4 UI of total jitter on the signal.
1–48 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
