Tektronix DPO70000 Series Technical Reference

Performance Tests (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
NOTE. As the inp
ut frequency is lowered, adjust the Horizontal SCALE to
maintain about 3 to 5 eyes across the display.
e. Verify that l
ock is acquired. (See Figure 3-37 on page 3-113.)
f. Repeat substeps b through d for each input frequency and Baud rate listed
in the table
. (See Table 3-15 on page 3-112.).
g. If all tests pass, enter passed in the t est record.
3. Disconnect the hookup: Disconnect the equipment from the instrument.
Table 3-15: Clock recovery input frequencies and baud rates
Input frequency Recovered clock baud rate
≥ 4 GHz models
1.5625 GHz
3125 Mbaud
781.25 MHz 3125 Mbaud
742.19 MHz 2968.8 Mbaud
600 MHz 2400 Mbaud
575.00 MHz 2300 Mbaud
546.25 MHz 2185 Mbaud
390.63 MHz
1.5625 Gbaud
388.13 MHz
1.5525 Gbaud
< 4 GHz models
625 MHz
1.25 Gbaud
321.5 MHz
1.25 Gbaud
296.87 MHz
1.187 Gbaud
168.75 MHz 675 Mbaud
300 MHz 1200 Mbaud
156.25 MHz 625 Mbaud
78.12 MHz 312.5 Mbaud
74.21 MHz 296.48 Mbaud
31.25 MHz 125 Mbaud
15.62 MHz 62.5 Mbaud
7.81 MHz 31.25 Mbaud
3.9 MHz 15.65 Mbaud
1.95 MHz 7.81 Mbaud
976.56 kHz 3.9 Mbaud
488.28 kHz 1.95 Mbaud
380.98 kHz 1.52 Mbaud
3–112 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
