Tektronix DPO70000 Series Technical Reference

Specifications (MSO70000/C Series, DSA/DPO70000B/C Series, and DPO7000 Series)
Table 1-6: Input/output port specifi cations, all MSO70000/C, DSA/DPO70000B/C, and DPO7000 Series models (cont.)
Characteristic Description
External reference, typical Run SPC whenever the external reference is more than 0.1% (1000 ppm) different than the
nominal reference or the reference at which S PC was last run.
The timebase changes in correspondence to the fluctuations in the external reference.
Input frequency ≥ 4 G Hz models: 10 MHz
< 4 GHz models: 10 MHz
Input sensitivity
≥ 4 GHz models: ≥ 200 mV
p-p
< 4 GHz models: ≥ 1.5 V
p-p
Input voltage, maximum 7 V
p-p
Input impedance
≥ 4 GHz models: 1.5 kΩ,C
in
= 40 pF, measured at >100 kHz
< 4 GHz models: 385 Ω,C
in
= 137 pF, measured at 10 MHz
≥ 4 GHz models: Low (stable) jitter mode: ± 100 ppm
High (tracking) jitter mode: ± 1%
Running SPC i s required whenever the external reference is more than 0.1% (1000 ppm)
different from the nominal reference frequency or reference at which SPC was last run.
Input frequency variation
tolerance
< 4 GHz models: 9.8 MHz to 10.2 MHz
Internal reference output
≥ 4 GHz models: 10 MHz
Frequency
< 4 GHz models: 10 MHz available at AUXOUT
Output voltage, typical
≥ 4 GHz models
> 750 mV peak-peak into 50 Ω
> 1.5 V peak-peak into 1 M Ω (internally A C coupled).
V
out
high
V
out
low (true)< 4 GHz models
≥2.5 V into open circuit,
≥1.0 V into 50 Ω load to ground
≤0.7Vwith≤4mAsink,
≤0.25 V into 50 Ω load to ground
1–54 MSO70000/C, DSA70000B/C, DPO7000B/C, DPO7000, MSO5000, DPO5000 Series
