Tektronix TDS3000 Series User Manual

Save/Recall
3–40
TDS3000 Series User Manual
Save/Recall
Push the SAVE/RECALL button to show the save/recall menu.
Bottom Side Description
S
a
ve
C
u
rre
n
t
Set
To File Saves a setup to disk.
Set
up
To Setup 1
...
To Setup 10
Saves a setup to nonvolatile memory.
R
ec
a
ll
S
a
ve
d
Set
-
From File Recalls a setup from disk.
up
Recall Setup 1
...
Recall Setup 10
Recalls a setup from nonvolatile
memory.
Recall Factory
Setup
OK Confirm
Factory Init
Initializes the setup.
S
a
ve
W
f
m
To File Shows file-format choices: Internal,
Spreadsheet, or Mathcad (see
page 3–44). Saves the selected
waveform to disk.
To Ref1
...
To Ref4
Saves the selected waveform to
nonvolatile memory.
Recall Wfm From File
Recall Ref1
...
Recall Ref4
Recalls a waveform from disk and
displays it as a reference waveform.
File Utilities Accesses floppy disk file utilities. Refer to description on
page 3–43.
Labels Lets you assign unique labels to reference waveforms and
instrument setups stored in nonvolatile memory. Refer to
page 3–45 for a description of how to edit label text.
SA
VE
/
RE
CA
LL
