TDS3000 Series User Manual
B–1
Appendix B: Factory Setup
The table below lists the state of the oscilloscope after you recall the
Factory Setup.
Control Changed by factory setup to
Acquire horizontal resolution Normal (10,000 points)
Acquire mode Sample
Acquire number of averages 16
Acquire number of envelopes 16
Acquire run/stop Run
Acquire single sequence Off
Channel selection Channel 1 on, all others off
Coarse No change
Confirm delete No change
Cursor function Off
Cursor H Bar 1 position –3.2 divisions from the center
Cursor H Bar 2 position +3.2 divisions from the center
Cursor H Bar units Base
Cursor V Bar 1 position 10% of record
Cursor V Bar 2 position 90% of record
Cursor V Bar units Seconds
Cursor tracking Independent
