Appendix D: Probe Basics
D–10
TDS3000 Series User Manual
Using Other Probes
Optional probes can add capabilities to your oscilloscope that are
useful in many applications.
Passive Probes
You can use the following passive probes without any limitations.
Passive probe Recommended usage
P6561A SMT probe, 200 MHz, 10X
P6562A SMT probe, 350 MHz, 10X
P6563A SMT probe, 500 MHz, 20X
P5100 High-voltage probe, 2500 V
pk
CAT II, 250 MHz, 100X
P6015A High-voltage probe, 20 kV DC, 75 MHz, 1000X
P6021 Current probe, 15 A, 120 Hz to 60 MHz
P6022 Current probe, 6 A, 935 Hz to 120 MHz
