Acquisition Controls
3–2
TDS3000 Series User Manual
Acquisition Controls
Run/Stop Button
Push the RUN/STOP button to stop and start waveform acquisition.
Also push RUN/STOP when you want to resume continuous
acquisition after a single-sequence acquisition. Readout in the top
left corner of the display shows the status of the acquisition.
Acquisition status readout Description
Run: Acquisition is running.
Roll: A roll-mode acquisition is running.
Stop: Acquisition is stopped.
PreVu: Previewing; waiting for trigger.
While acquisition is running or stopped, you can use these controls
to examine the waveforms:
Channel buttons to select a channel
Zoom button
with horizontal POSITION and SCALE to
magnify waveforms (does not affect the actual time base or
trigger position settings)
WAVEFORM INTENSITY to adjust gray-scale level
CURSOR button to activate cursors to measure waveforms
MEASURE button to select automatic measurements of
waveforms
Hard copy button to print a hard copy
While acquisition is stopped, you can change the vertical and
horizontal controls to use in the next acquisition. See page 3–7 for
more information about this function.
