TDS3000 Series User Manual
A–1
Appendix A: Specifications
This appendix contains specifications for the TDS3000 Series
oscilloscopes. All specifications are guaranteed unless noted as
“typical.” Typical specifications are provided for your convenience
but are not guaranteed. Specifications that are marked with the
n symbol are checked in Appendix E: Performance Verification.
All specifications apply to all TDS3000 models unless noted
otherwise. To meet specifications, two conditions must first be met:
H The oscilloscope must have been operating continuously for ten
minutes within the operating temperature range specified.
H You must perform the Compensate Signal Path operation
described on page 1–4. If the operating temperature changes by
more than 10° C, you must perform the Compensate Signal Path
operation again.
Specifications
Acquisition
Acquisition modes Sample (Normal), Peak detect, Envelope, and Average
ng
u
n
Acquisition mode Acquisition stops after
Sample, Peak Detect One acquisition, all channels
simultaneously
Average, Envelope N acquisitions, all channels
simultaneously, N is settable
from 2 to 256 (or ∞ for Enve-
lope)
