Page #93 background image
Cursor
TDS3000 Series User Manual
3–13
Bottom DesriptionSide
V Ba
r
U
n
it
s
Sec (s) /
1/sec (Hz)
Sets horizontal units to seconds or
frequency (Hz).
Ratio (%) Sets V Bar measurement units to
percent.
Phase (°) Sets V Bar measurement units to
degrees.
Use Cursor Posi-
tions as %/°
Sets the V Bar measurement scale so
that 0% or 0° is the current position of
the left V Bar cursor and 100% or
360° is the current position of the right
V Bar cursor.
Use 5 divs as %/° Sets the V Bar measurement scale so
that 5 screen major divisions is 100%
or 360°, where 0% or 0° is –2.5
divisions and 100% or 360° is +2.5
divisions from center vertical graticule.
