Texas Instruments bq78350-R1 Technical Reference

0x00 ManufacturerAccess() and 0x44 ManufacturerBlockAccess() www.ti.com
114
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
SBS Commands
SU (Bit 13): Charge Suspend
1 = Active
0 = Inactive
IN (Bit 12): Charge Inhibit
1 = Active
0 = Inactive
RSVD (Bits 11–10): Reserved. Do not use.
FCHG (Bit 9): FAST-CHARGE mode
1 = Active
0 = Inactive
PCHG (Bit 8): PRE-CHARGE mode
1 = Active
0 = Inactive
RSVD (Bits 7–5): Reserved. Do not use.
OT (Bit 4): Overtemperature Region
1 = Active
0 = Inactive
HT (Bit 3): High Temperature Region
1 = Active
0 = Inactive
ST (Bit 2): Standard Temperature Region
1 = Active
0 = Inactive
LT (Bit 1): Low Temperature Region
1 = Active
0 = Inactive
UT (Bit 0): Undertemperature Region
1 = Active
0 = Inactive
17.2.40 ManufacturerAccess() 0x0056 GaugingStatus
This command returns the GaugingStatus() flags on ManufacturerBlockAccess() or ManufacturerData().
Status Condition Action
Activate 0x0056 to ManufacturerAccess()
Outputs GaugingStatus() flags on
ManufacturerBlockAccess() or ManufacturerData().
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
VDQ EDV2 EDV1 RSVD RSVD FCCX OCVFR REST CF DSG EDV0 BAL_OK TC TD FC FD
VDQ (Bit 15): Discharge Qualified for Learning (based on the RU flag)
1 = Detected
0 = Not Detected
EDV2 (Bit 14): End-of-Discharge Voltage Level 2
