SBS Commands
17.3 0x01 RemainingCapacityAlarm()
This read- or write-word function sets or gets a low-capacity alarm threshold value. The default value for
RemainingCapacityAlarm is stored in Rem Cap Alarm. If RemainingCapacityAlarm() is set to 0, the alarm
is disabled. If RemainingCapacity() < RemainingCapacityAlarm(), the [RCA] flag is set and the bq78350-
R1 sends an AlarmWarning() message to the SMBUS host. If RemainingCapacity() ≥
RemainingCapacityAlarm() and [DSG] is set, the [RCA] flag is cleared. 0 = remaining capacity alarm is
disabled. 1..700 = the remaining capacity limit for [RCA] flag.
SBS
Cmd
Name
Access
Proto-
col
Type Min Max Default Unit Note
SE US FA
0x01 RemainingCapacityAlarm() R/W Word U2 0 700 300
mAh BatteryMode()[CAPM] = 0
10 mWh BatteryMode()[CAPM] = 1
The threshold value is stored in the following data flash location.
Class Subclass Name Type Min Max Default Unit Description
SBS
Configuration
Data
Remaining
Capacity
Alarm
U2 0 700 300 mAh RemainingCapacityAlarm() value in mAh
SBS
Configuration
Data
Remaining
Capacity
Alarm
U2 0 1000 432 cWh RemainingCapacityAlarm() value in 10 mWh
17.4 0x02 RemainingTimeAlarm()
This read- or write-word function sets or gets the RemainingTimeAlarm() value. The default value of
RemainingTimeAlarm() is stored in Rem Time Alarm. If RemainingTimeAlarm() = 0, this alarm is
disabled. If AverageTimeToEmpty() < RemainingTimeAlarm(), the [RTA] flag is set and the bq78350-R1
sends an AlarmWarning() message to the SMBus host. If AverageTimeToEmpty() ≥
RemainingTimeAlarm(), the [RTA] flag is reset.
0 = remaining time alarm is disabled. 1..30 = the remaining time limit for the [RTA] flag.
SBS
Cmd
Name
Access
Proto-
col
Type Min Max Default Unit
SE US FA
0x02 RemainingTimeAlarm() R/W Word U2 0 30 10 min
The threshold value is stored in the following data flash location.
Class Subclass Name Type Min Max Default Unit Description
SBS
Configuration
Data
Remaining
Time Alarm
U2 0 30 10 min RemainingTimeAlarm() value
17.5 0x03 BatteryMode()
This read- or write-word function selects the various battery operational modes, reports the battery's
capabilities and modes, and flags minor conditions that require attention.
SBS
Cmd
Name
Access
Protocol Type Min Max Unit
SE US FA
0x03 BatteryMode() R/W Word H2 0x0000 0xFFFF —
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
CAPM CHGM AM RSVD RSVD RSVD PB CC CF RSVD RSVD RSVD RSVD RSVD PBS ICC
