SBS Commands
1 = EDV2 voltage is reached during discharge.
0 = EDV2 voltage is not reached, or not in DISCHARGE mode.
EDV1 (Bit 13): End-of-Discharge Voltage Level 1
1 = EDV1 voltage is reached during discharge.
0 = EDV1 voltage is not reached, or not in DISCHARGE mode.
RSVD (Bits 12–11): Reserved. Do not use.
FCCX (Bit 10): FullChargeCapacity() has been updated. This bit changes state each time
FullChargeCapacity() updates.
OCVFR (Bit 9): Reserved and not used.
REST (Bit 8): Rest
1 = OCV Reading Taken
0 = OCV Reading Not Taken or Not in Relax
CF (Bit 7): Condition Flag
1 = MaxError() > Max Error Limit (Condition Cycle needed)
0 = MaxError() < Max Error Limit (Condition Cycle not needed)
DSG (Bit 6): Discharge/Relax
1 = Charging Not Detected
0 = Charging Detected
EDV0 (Bit 5): End-of-Discharge Voltage Level 0 (Termination)
1 = Termination voltage is reached during discharge.
0 = Termination voltage is not reached, or not in DISCHARGE mode.
BAL_OK (Bit 4): Cell Balancing
1 = Cell balancing is possible if enabled.
0 = Cell balancing is not allowed.
TC (Bit 3): Terminate Charge
1 = Detected
0 = Not Detected
TD (Bit 2): Terminate Discharge
1 = Detected
0 = Not Detected
FC (Bits 1): Fully Charged
1 = Detected
0 = Not Detected
FD (Bit 0): Fully Discharged
1 = Detected
0 = Not Detected
17.2.41 ManufacturerAccess() 0x0057 ManufacturingStatus
This command returns the ManufacturingStatus() flags on ManufacturerBlockAccess() or
ManufacturerData().
Status Condition Action
Activate 0x0057 to ManufacturerAccess()
Outputs ManufacturingStatus() flags on
ManufacturerBlockAccess() or ManufacturerData().
