SBS Commands
Chapter 17
SLUUBD3D–September 2015–Revised September 2018
SBS Commands
17.1 Summary
Table 17-1. SBS Commands Summary
SBS
Cmd
Mode Name Format
Size in
Bytes
Min Max Default Unit
0x00 R/W ManufacturerAccess hex 2 0x0000 0xFFFF —
0x01 R/W RemainingCapacityAlarm unsigned int 2 0 65535 300
mAh or 10
mWh
0x02 R/W RemainingTimeAlarm unsigned int 2 0 65535 10 min
0x03 R/W BatteryMode hex 2 0x0000 0xFFFF —
0x04 R/W AtRate integer 2 –32768 32767 —
mAh or 10
mWh
0x05 R AtRateTimeToFull unsigned int 2 0 65534 — min
0x06 R AtRateTimeToEmpty unsigned int 2 0 65534 — min
0x07 R AtRateOK unsigned int 2 0 65535 —
0x08 R Temperature unsigned int 2 0 65535 — 0.1°K
0x09 R Voltage unsigned int 2 0 65535 — mV
0x0A R Current integer 2 –32768 32767 — mA
0x0B R AverageCurrent integer 2 –32768 32767 — mA
0x0C R MaxError unsigned int 1 0% 100% —
0x0D R RelativeStateOfCharge unsigned int 1 0% 100% —
0x0E R AbsoluteStateOfCharge unsigned int 1 0% 100+% —
0x0F R/W RemainingCapacity unsigned int 2 0 65535 —
mAh or 10
mWh
0x10 R FullChargeCapacity unsigned int 2 0 65535 —
mAh or 10
mWh
0x11 R RunTimeToEmpty unsigned int 2 0 65534 — min
0x12 R AverageTimeToEmpty unsigned int 2 0 65534 — min
0x13 R AverageTimeToFull unsigned int 2 0 65534 — min
0x14 R ChargingCurrent unsigned int 2 0 65534 — mA
0x15 R ChargingVoltage unsigned int 2 0 65534 — mV
0x16 R BatteryStatus unsigned int 2 0x0000 0xdbff —
0x17 R CycleCount unsigned int 2 0 65535 —
0x18 R DesignCapacity unsigned int 2 0 65535 —
mAh or 10
mWh
0x19 R DesignVoltage unsigned int 2 0 65535 — mV
0x1A R SpecificationInfo hex 2 0x0000 0xFFFF 0x0031
0x1B R ManufacturerDate unsigned int 2 0 65535 —
0x1C R SerialNumber hex 2 0x0000 0xFFFF 0x0001
0x20 R ManufacturerName string 11+1 — —
Texas
Instruments
ASCII
0x21 R DeviceName string 7+1 — — bq78350 ASCII
0x22 R DeviceChemistry string 4+1 — — LION ASCII
0x23 R ManufacturerData String 14+1 — — — ASCII
0x2B R/W HostFETControl hex 2 0 65535 —
0x2C R GPIOStatus hex 2 0 65535 —
0x2D R/W GPIOControl hex 2 0 65535 —
