SBS Commands
17.32 0x21 DeviceName()
This read-block function returns the assigned pack name stored in Device Name.
SBS
Cmd
Name
Access
Protocol Type Length in Bytes Min Max Unit
SE US FA
0x21 DeviceName() R R R Block String 7+1 — — ASCII
Class Subclass Name Format Length in Bytes Min Max Default Unit
SBS Configuration Data Device Name String 8 — — bq78350-R1 ASCII
17.33 0x22 DeviceChemistry()
This read-block function returns the battery chemistry used in the pack stored in Device Chemistry.
SBS
Cmd
Name
Access
Protocol Type Length in Bytes Min Max Unit
SE US FA
0x22 DeviceChemistry() R R R Block String 4+1 — — ASCII
Class Subclass Name Format Length in Bytes Min Max Default Unit
SBS Configuration Data Device Chemistry String 5 — — LION ASCII
17.34 0x23 ManufacturerData()/CalibrationData()
This read-block function returns several elements of manufacturing-related pack information in the default
mode. It is also used to return a variety of other data and can provide measured voltage, current, and
temperature data for calibration purposes in CALIBRATION mode. See Section 17.2,
ManufacturerAccess(), for more details on these options.
SBS
Cmd
Name
Access
Protocol Type Min Max Unit Note
SE US FA
0x23 ManufacturerData() R R R Block S32+1
Status Condition Action
ManufacturerData Valid command sent
Returns pack information on
ManufacturerData()
The default data returned by ManufacturerData() is stored in the following data flash.
Class Subclass Name Format Length in Bytes Min Max Default Unit
SBS Configuration Data Manufacturer Info String 33 — — — ASCII
When the bq78350-R1 is in CALIBRATION mode, this command changes the data it returns. See
Calibration for more details on the data and format.
SBS
Cmd
Name
Access
Protocol Type Min Max Unit Note
SE US FA
0x23 CalibrationData() R R R Block H2+S24
