Texas Instruments bq78350-R1 Technical Reference

www.ti.com PF Status Snapshot Data Flash
43
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
Permanent Fail
Class Subclass Name Type Min Max Default Description
PF Status
Device Status
Data
PF Alert A H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Status A H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Alert B H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Status B H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Alert C H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Status C H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Alert D H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
PF Status D H1 0x00 0xFF 0 Accumulated PF flags since PF event
PF Status
Device Status
Data
SAFE Flag H2 0x0000 0xFFFF 0 Flag set to indicate SAFE activation
PF Status
Device Status
Data
Operation Status A H2 0x0000 0xFFFF 0 OperationStatus() data at the time of the PF event
PF Status
Device Status
Data
Operation Status B H2 0x0000 0xFFFF 0 OperationStatus() data at the time of the PF event
PF Status
Device Status
Data
Charging Status A H1 0x00 0xFF 0 ChargingStatus() data at the time of the PF event
PF Status
Device Status
Data
Charging Status B H1 0x00 0xFF 0 ChargingStatus() data at the time of the PF event
PF Status
Device Status
Data
Gauging Status A H1 0x00 0xFF 0 GaugingStatus() data at the time of the PF event
PF Status
Device Status
Data
Gauging Status B H2 0x0000 0xFFFF 0 GaugingStatus() data at the time of the PF event
4.20.2 Device Voltage Data
Class Subclass Name Type Min Max Default Unit Description
PF Status
Device Voltage
Data
Cell Voltage 1 I2 0 32767 0 mV Cell 1 voltage
PF Status
Device Voltage
Data
Cell Voltage 2 I2 0 32767 0 mV Cell 2 voltage
PF Status
Device Voltage
Data
Cell Voltage 3 I2 0 32767 0 mV Cell 3 voltage
PF Status
Device Voltage
Data
Cell Voltage 4 I2 0 32767 0 mV Cell 4 voltage
PF Status
Device Voltage
Data
Cell Voltage 5 I2 0 32767 0 mV Cell 5 voltage
PF Status
Device Voltage
Data
Cell Voltage 6 I2 0 32767 0 mV Cell 6 voltage
PF Status
Device Voltage
Data
Cell Voltage 7 I2 0 32767 0 mV Cell 7 voltage
PF Status
Device Voltage
Data
Cell Voltage 8 I2 0 32767 0 mV Cell 8 voltage
PF Status
Device Voltage
Data
Cell Voltage 9 I2 0 32767 0 mV Cell 9 voltage
PF Status
Device Voltage
Data
Cell Voltage 10 I2 0 32767 0 mV Cell 10 voltage
PF Status
Device Voltage
Data
Cell Voltage 11 I2 0 32767 0 mV Cell 11 voltage
PF Status
Device Voltage
Data
Cell Voltage 12 I2 0 32767 0 mV Cell 12 voltage
PF Status
Device Voltage
Data
Cell Voltage 13 I2 0 32767 0 mV Cell 13 voltage
PF Status
Device Voltage
Data
Cell Voltage 14 I2 0 32767 0 mV Cell 14 voltage
