Texas Instruments bq78350-R1 Technical Reference

0x00 ManufacturerAccess() and 0x44 ManufacturerBlockAccess() www.ti.com
122
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
SBS Commands
Status Condition Action
Disable
ManufacturingStatus()[CAL] = 1 AND 0xF080
to ManufacturerAccess()
ManufacturingStatus()[CAL] = 0
Stops output of ADC and CC data on
ManufacturerBlockAccess() or ManufacturerData()
Enable 0xF081 to ManufacturerAccess()
ManufacturingStatus()[CAL] = 1
Outputs the raw CC and AD values
ManufacturerBlockAccess() or ManufacturerData() in the
format of ZZYYaaAAbbBBccCCddDDeeEEffFF
ggGGhhHHiiIIjjJJkkKK:
ZZ: rolling 8-bit counter, increments when values are
refreshed.
YY: Status: 1 when ManufacturerAccess() = 0xF081;
2 when ManufacturerAccess() = 0xF082
AAaa: AFE Cell Map
BBbb: Cell Voltage 1
CCcc: Cell Voltage 2
DDdd: Cell Voltage 3
EEee: Cell Voltage 4
FFff: Cell Voltage 5
GGgg: Cell Voltage 6
HHhh: Cell Voltage 7
IIii: Cell Voltage 8
JJjj: Cell Voltage 9
KKkk: Cell Voltage 10
LLll: Cell Voltage 11
MMmm: Cell Voltage 12
NNnn: Cell Voltage 13
OOoo: Cell Voltage 14
17.2.62 ManufacturerAccess() 0xF082 OutputCellVoltageCCandTempforCalibration
This command instructs the device to output the raw values for calibration purposes on
ManufacturerBlockAccess() or ManufacturerData(). All values are updated every 250 ms and the format of
each value is 2's complement, MSB first. This mode includes an internal short on the coulomb counter
inputs for measuring offset.
Status Condition Action
Disable
ManufacturingStatus()[CAL] = 1 AND
0xF080 to ManufacturerAccess()
ManufacturingStatus()[CAL] = 0
Stop output of ADC and CC data on
ManufacturerBlockAccess() or ManufacturerData()
Enable 0xF081 to ManufacturerAccess()
ManufacturingStatus()[CAL] = 1
Outputs the raw CC and AD values on
ManufacturerBlockAccess() or ManufacturerData() in the
format of ZZYYaaAAbbBBccCCddDDeeEEffFF
ggGGhhHHiiIIjjJJkkKK:
ZZ: rolling 8-bit counter, increments when values are
refreshed.
YY: Status: 1 when ManufacturerAccess() = 0xF081;
2 when ManufacturerAccess() = 0xF082
AAaa: AFE Cell Map
BBbb: Cell Voltage 15
CCcc: Reserved
DDdd: ExtAveCellVoltage
EEeeFFff: VAUX Voltage
GGgg: Current (Coulomb Counter)
HHhh: TS1 Temperature
IIii: TS2 Temperature
JJjj TS3 Temperature
KKkk: Gauge Temperature
