Texas Instruments bq78350-R1 Technical Reference

Charge Suspend www.ti.com
52
SLUUBD3D–September 2015–Revised September 2018
Submit Documentation Feedback
Copyright © 2015–2018, Texas Instruments Incorporated
Charge Algorithm
5.7 Charge Suspend
The device can suspend charging at high and low temperatures to prevent damage of the cells. Care
should be taken to ensure Charge Inhibit and Charge Suspend features are configured correctly as upon
Charge Suspend detection [CHGSU=1], then Charge Inhibit detection criteria will have to be passed prior
to restarting charge.
Status Condition Action
Normal
BatteryStatus()[DSG] = 0
Charge Inhibit/Suspend Low Temp <
Temperature() < Charge Suspend High
Temp
ChargingStatus()[SU] = 0
ChargingVoltage() = charging algorithm
ChargingCurrent() = charging algorithm
Trip
BatteryStatus()[DSG] = 0
Charge Inhibit/Suspend Low Temp >
Temperature() > Charge Suspend High
Temp
ChargingStatus()[SU] = 1
ChargingVoltage() = 0
ChargingCurrent() = 0
No charging is allowed if FET Options[CHGSU] = 1.
Class Subclass Name Type Min Max Default Unit
Charge Algorithm Temperature Ranges Charge Suspend High Temp I1 –127 128 55 °C
