100 RT-SVP04F-EN
System Programming SETPOINTS
Used With: All units.
End Of Submenu (NEXT) To ENTER SRC SEL
1. Press the NEXT key to leave the submenu and show following
screen.
2. Press PREVIOUS to page back through the submenu.
For Min Outside Air Flow Rate Ctrl, Use Used With: All Units when VCM and
GBAS is installed
Factory Presets: HI (KEYPAD)
SETPOINT MENU
Possible Values: HI (KEYPAD)
SETPOINT MENU, GBAS 0-5 VDC
MODULE, GBAS 0-10VDC Module
SETPOINT From: HI (KEYPAD) SETPOINT MENU
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
For Supply Air Pressure Control, Use Used With: All Units when IGV/VFD
and GBAS 0-5 VDC Module is
installed or GBAS 0-10VDC is
installed
Factory Presets: Factory
Presets: HI (Keypad) SETPOINT
Menu
Possible Values: HI (KEYPAD)
SETPOINT MENU, GBAS 0-5VDC
GBAS 0-10VDC
SETPOINT From: HI (KEYPAD) SETPOINT MENU
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
For Space Pressure Control, Use Used With: All Units when Power
Exhaust with Statitrac is installed
and GBAS 0-5VDC or GBAS 0-
10VDC
Factory Presets: HI (KEYPAD)
SETPOINT MENU
Possible Values: HI (KEYPAD)
SETPOINT MENU, GBAS 0-5 VDC
MODULE, GBAS 0-10VDC Module
SETPOINT From: HI (KEYPAD) SETPOINT MENU
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
End Of Submenu (NEXT) To Enter SETPOINT
1. Press the NEXT key to leave the submenu and show following
screen.
2. Press PREVIOUS to page back through the submenu.
