Trane IntelliPak I User Manual

76 RT-SVP04F-EN
System Programming SETUP
Assign Diagnostic to Alarm Output? Used With: All units. (if ENTER
pressed above)
Possible values: YES/NO; Lvg Evap
Temp Sensor Fail - Ckt 1, Lvg Evap
Temp Sensor Fail - Ckt 2, Low Pres
Control Open - Ckt 1, Low Pres
Control Open - Ckt 2, Cond Temp
Sensor Failure - Ckt 1, Cond Temp
Sensor Failure - Ckt 2, Compressor
Trip - Ckt 1, Compressor Trip - Ckt
2, MCM Communications Failure,
Comp, Contactor Fail - Ckt 1, Comp
Contactor Fail - Ckt 2, High Super
Heat - Ckt 1, Low Refrigerant
Charge - Ckt 1, High Super Heat -
Ckt 2, Low Refrigerant Charge - Ckt
2, Enter Evap Temp Sensor Fail -Ckt
1, Enter Evap Temp Sensor Fail -Ckt
2
________________________ YES
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
Assignment Submenu - HEAT Alarms Used With: All units with Heat
installed. (if "Any Active Diagnostic"
NO is selected above)
Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Assign Diagnostic to Alarm Output? Used With: All units with Heat
installed. (if ENTER pressed above)
Possible values: YES/NO; HEAT
Aux Temp Sensor Fail, Low Air Temp
Limit Trip, Heat Failure, Heat Module
Comm Failure
_________________________ YES
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
Assignment Submenu - ECEM Alarms Used With: All units. (if "Any Active
Diagnostic" NO is selected above)
Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Assign Diagnostic to Alarm Output? Used With: All units with ECEM
installed. (if ENTER pressed above)
Possible values: YES/NO; Space
Static Pres Setpt Failure, Space
Pressure Sensor Failure, Return Air
Temp Sensor Failure, RA Humidity
Sensor Failure, ECEM
Communications Failure
_________________________ YES
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
