System Operating Status
Active Space Pressure SETPOINT From
HI (KEYPAD) SETPOINT MENU is 0.08 IWC
Used With: All Units when Power
Exhaust with Statitrac is installed or
Return Fan with Statitrac installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0-5 VDC
Module, BAS/Network, GBAS 0-10
VDC Module; SETPOINT range: -0.2
to 0.30 IWC
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Space Pressure Deadband 0.10 IWC
Used With: All Units when Power
Exhaust with Statitrac is installed or
Return Fan with Statitrac Installed
Possible Values: HI (KEYPAD)
SETPOINT MENU, SETPOINT range:
0.02 to 0.20 IWC
1. Press the NEXT key until the following screen is displayed.
End of Submenu (NEXT) to Enter SETUP Status
1. Press the NEXT key to leave the submenu and show following
screen.
2. Press PREVIOUS to page back through the submenu.
CONTROLLING SENSOR STATUS SUBMENU SCREENS
Controlling Sensor Status Submenu
Press ENTER to View Data in This Submenu
Used With: All Units
1. Pressing the NEXT key will bypass this section.
Active Supply Air Temp Sensor Input From
SUPPLY AIR is 50.0 F
Used With: All Units
Possible Values: RTM Supply Air
Temp Input, BAS/Network
1. Press the NEXT key until the following screen is displayed.
Active Daytime WU Temp Sensor Input From
RTM ZONE TEMP INPUT is 82.0 F
Used With: All units when Gas,
Electric, Hydronic or External Heat is
installed and DWU is enabled
Possible Values: RTM Zone Temp
Input, NSB Panel Temp Sensor
Input, RTM Aux Temp Input, Heat
Module Aux Temp Input, ECEM
Return Air Temp Input, BAS/Network
Sensor range: -40 F to 200 F
1. Press the NEXT key until the following screen is displayed.(if
applicable)
Active Unocc Zone Temp Sensor Input From
RTM ZONE TEMP INPUT is 75.0 F
Used With: All Units
Possible Values: RTM Zone Temp
Input, NSB Panel Temp Sensor
Input, RTM Aux Temp Input, Heat
Module Aux Temp Input, ECEM
Return Air Temp Input, BAS/
Network, Sensor range: -40 F to
200 F
1. Press the NEXT key until the following screen is displayed. (if
applicable)
