Trane IntelliPak I User Manual

RT-SVP04F-EN 43
System Operating Status
Active Min OA Flow SETPOINT From
HI (KEYPAD) SETPOINT MENU 34.2 CFM
Used With: All Units when Fresh
Air Measurement VCM is installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0 - 5 VDC
Module, BAS Network GBAS 0-10
VDC Module SETPOINT range: 0 to
Max Unit Airflow
Refer to the table in the SETPOINT
section, "Default Min OA Flow
SETPOINT Screen" for max airflow
SETPOINTs.
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Design Min OA Flow SETPOINT
From HI (KEYPAD) SETPOINT MENU
34.2 CFM
Used With: All Units when Fresh
Air Measurement VCM is installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0 - 5 VDC
Module, BAS Network GBAS 0-10
VDC Module SETPOINT range: 0 to
Max Unit Airflow
Refer to the table in the SETPOINT
section, "Default Min OA Flow
SETPOINT Screen" for max airflow
SETPOINTs.
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Min OA Flow Stp DCV Disabled Used With: All Units when Fresh
Air Measurement VCM is installed
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0 - 5 VDC
Module, BAS Network GBAS 0-10
VDC Module SETPOINT range: 0 to
Max Unit Airflow
Refer to the table in the SETPOINT
section, "Default Min OA Flow
SETPOINT Screen" for max airflow
SETPOINTs.
1. Press the NEXT key until the following screen is displayed. (if applicable)
Active Supply Air Pressure STP From
HI (KEYPAD) SETPOINT MENU is 2.0 IWC
Used With: Rooftop units and Air
Handlers when IGV/VFD is installed.
Possible Values: HI (Keypad)
SETPOINT Menu, GBAS 0-5 VDC
Module, GBAS 0-10 VDC Module,
BAS/Network SETPOINT Range:
0.7=5.1 IWC
1. Press the NEXT key until the following screen is displayed.
Active Supply Air Pressure SETPOINTS
High Limit: 4.0 IWC Deadband: 0.5 IWC
Used With: Rooftop units and Air
Handlers with IGV/VFD installed or
with SAP present.
Possible Values: High Limit: 1.2 -
4.7 IWC Deadband: 0.1 - 2.0 IWC
1. Press the NEXT key until the following screen is displayed.
