RT-SVP04F-EN 39
System Operating Status
Outside Air Bypass Damper Pos: 0% Used With: All IntelliPak II units
with Energy Recovery installed.
Possible Values: 0-100%
Exhaust Air Bypass Damper Pos: 15%
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the NEXT key until the following screen is displayed.
(if applicable)
Energy Wheel Frost Avoidance: INACTIVE Used With: All IntelliPak II units
with Energy Recovery installed.
Possible Values: Frost Avoidance:
ACTIVE, INACTIVE;
Recovery Exhaust Temp: -40.0 to
200.0 F
Leaving Recovery Exhaust Temp: 45.0°F
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the NEXT key until the following screen is displayed.
(if applicable)
Energy Wheel Preheat Relay: OFF Used With: All IntelliPak II units
with Energy Recovery Preheat
installed.
Possible Values: ON, OFF
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the NEXT key until the following screen is displayed.
(if applicable)
CONTROLLING SETPOINT STATUS SUBMENU SCREENS
Controlling SETPOINT Status Submenu
Press ENTER to View Data in This Submenu
Used With: All Units
1. Pressing the NEXT key will bypass this section.
Active Supply Air Cooling STP From
HI (KEYPAD) SETPOINT MENU Is 55 F
Used With: All Units
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the + (Plus) key while viewing any screen to add that
screen to the custom menu. Refer to the custom menu for the
creation and maintenance of customized menus.
4. Press the NEXT key until the following screen is displayed.
(if applicable)
Possible Values: HI (Keypad)
SETPOINT Menu, Zone Sensor
SETPOINT Input, NSB Panel
SETPOINT Input, GBAS 0-5 VDC
Module, BAS/Network, GBAS 0-10
VDC Module
To Next Page
