64 RT-SVP04F-EN
System Programming SETUP
OA flow Compensation Function: DISABLED Used With: All Units without Fresh
Air measurement (VCM) with an
economizer when IGF/VFD is
installed
Factory Preset: Disabled
Possible Values: ENABLED,
DISABLED
Enabled 2nd line= "OA Damper Min
Pos Depends on IGV/VFD Pos"
Disabled 2nd line= "Use Fixed OA
Damper Minimum Position"
Use fixed OA Damper Minimum Position
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key until the following screen is displayed.
OA Flow Calibration Data (Front) Used With: All units with Fresh Air
Measurement w/DCV (VCM)
installed.
Factory Preset: Gain 1.0, Offset 0
CCFM
Possible Values: Gain= 0.5 to 1.5
(Default 1.0); Offset= -250 to 250
CCFM (Default 0 CFM)
Note: Front refers to the flow
station on the "Front" of the
unit (See Installation,
Operation, Maintenance
Manual)
Gain 1.0 Offset 0 CCFM
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
OA Flow Calibration Data (Back) Used With: All units with Fresh Air
Measurement w/DCV (VCM)
installed.
Factory Preset: Gain 1.0, Offset 0
CCFM
Possible Values: Gain= 0.5 to 1.5
(Default 1.0); Offset= -25 to 25
CCFM
Note: Back refers to the flow
station on the "Back" of the
unit (See Installation,
Operation, Maintenance
Manual)
Gain 1.0 Offset 0 CCFM
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
