Universal Audio Arrow User Manual

Arrow Manual Console Plug-In Inserts 145
Plug-In Editor Window
Clicking any insert that contains a plug-in opens the editor window, where UAD plug-in
parameters can be adjusted and/or plug-in presets are managed.
Multiple editor windows can be open simultaneously. By default, each opened editor
window is offset so one window doesn’t completely cover another.
Tip: To open each editor window at the same screen location, shift+click the insert.
Refer to the illustration below for element descriptions in this section.
Plug-In editor window elements within Console
Title Bar
The editor window’s title bar is displayed at the top of each editor window.
Console Channel Name – The Console strip containing the insert is displayed.
Console Insert Slot – The insert slot number (1 – 4) or Unison is displayed.
Close – Closes the editor window.
Minimize – Minimizes the editor window by placing it in the Dock (Mac) or Taskbar
(Windows). Click the minimized window to restore.
Function
Buttons
Title
Bar
Close Minimize Console Channel Name Console Insert Slot
UAD
Toolbar
(controls in main window area vary per UAD plug-in)
Channel Strip
Enable/Disable
Insert
Select/Assign
Menu
Plug-In
Controls
Presets
Manager
Popover
Preset Manager Menu
(use within DAW)
14-Day Demo Status
(if unlicensed)
Information Menu
(manual & web page)
Plug-In
Power
(disable)
Copy
Plug-In
Settings
Paste
Plug-In
Settings
Buy Plug-In
(if unlicensed)
