Arrow Manual UAD Meter & Control Panel 196
UAD Meter & Control Panel
The UAD Meter & Control Panel application is used to monitor and configure UAD device
resources. It has two main windows: the UAD Meter, and the UAD Control Panel.
The UAD Meter displays the current DSP, program, and memory status of UAD devices
in realtime. The UAD Control Panel has multiple panels that display and modify various
system, plug-in, and global configuration parameters.
Note: This application is with all UAD device models (Arrow/Apollo audio
interfaces and UAD-2 DSP Accelerators).
UAD Meter Window
The UAD Meter & Control Panel application can be launched or quit at any time. It does
not need to be open or active to use Arrow or UAD plug-ins. It is completely independent
and does not require Console or a DAW. You can move the UAD Meter to a convenient
location on your screen by dragging its window title bar.
Note: If “No Devices Found” appears in the UAD Meter window instead of the
expected buttons and gauges, the UAD software is not communicating with the
UAD hardware. If this occurs, double-check hardware and software installations
and/or contact Technical Support.
Launching the Application
The UAD Meter & Control Panel application can be opened using the
techniques listed for each operating system below.
Windows
• Access the application from:
Start Menu>All Programs>UAD Powered Plug-Ins
Mac
• Single-click the UAD Meter & Control Panel icon that was placed in the macOS
Dock during installation
• Double-click the UAD Meter & Control Panel application that was installed at:
/Applications/Universal Audio/
UAD Meter &
Control Panel
application icon
