Universal Audio Arrow User Manual

Arrow Manual Specifications 249
Specifications
All specifications are typical performance unless otherwise noted, tested under the
following conditions: 48 kHz internal sample rate, 24-bit sample depth, 20 kHz
measurement bandwidth, with balanced inputs and outputs.
SYSTEM
I/O Complement
Microphone Inputs Two
Analog Line Inputs Two
Hi-Z Instrument Inputs One
Analog Monitor Outputs Two (one stereo pair)
Headphone Outputs One stereo
Thunderbolt 3 Port One
A/D – D/A Conversion
Supported Sample Rates (kHz) 44.1, 48, 88.2, 96, 176.4, 192
Bit Depth Per Sample 24
Simultaneous A/D conversion Two channels
Simultaneous D/A conversion Four channels
Analog Round-Trip Latency 1.1 milliseconds @ 96 kHz sample rate
Analog Round-Trip Latency with up to five serial
UAD Powered Plug-Ins via Console application
1.1 milliseconds @ 96 kHz sample rate
(continued)

Universal Audio Arrow Specifications

General

Brand	Universal Audio
Model	Arrow
Category	Recording Equipment
Language	English
