2GM
1-6-9
1-6-7 Removing the primary cir
cuit PWBs
(1) Removing the engine PWB
1.
Remove the right cover (see page 1-6-4).
2.
Remov
e all (twelv
e) connectors from the engine PWB.
3.
Remove three screws.
4.
Remov
e the engine PWB.
*
When replacing the PWB with a new PWB
,
remov
e the EEPROM from the old PWB and
mount it to the new PWB
.
Figure 1-6-11 Removing the engine PWB
Screws
Engine PWB
EEPROM
101
103
