(9) Adjusting the DP magnification
Adjust magnification in the auxiliary scanning direction if magnification is incorrect when the DP is used.
U070
U065
(P. 1-6-44)
Caution:
Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode.
Procedure
Original Copy
example 1
Copy
example 2
Enter maintenance mode.
Place an original on the DP
and make a test copy.
(Printing cannot be stopped until the
preset number of sheets is printed.)
Yes
No
Start
End
Press the back key
to exit maintenance mode.
Is the image correct?
Enter 070 using
up/down cursor keys.
Press the system menu/counter key.
Setting range: -25 to +25
Initial setting: -2
Changing the value by 1 changes
the magnification by 0.1%.
Increase the value makes
the image longer, and decreasing it
make the image shorter.
Press the system menu/counter key.
For copy example 1, increase the
value using the right cursor key.
For copy example 2, decrease the
value using the left cursor key.
Press the enter key.
Press the enter key.
The new setting is stored.
