(12) Adjusting the DP center line
Perform the following adjustment if there is a regular error between the centers of the original and the copy image.
U034
(P. 1-6-42)
U067
(P. 1-6-47)
U072
Caution:
Before making the following adjustment, ensure that the above adjustments have been made in maintenance mode.
Procedure
Original Copy
example 1
Copy
example 2
Reference
Enter maintenance mode.
Place an original on the DP
and make a test copy.
(Printing cannot be stopped until the
preset number of sheets is printed.)
Yes
No
Start
End
Press the system menu/counter key.
For copy example 1, increase the
value using the right cursor key.
For copy example 2, decrease the
value using the left cursor key.
Press the back key
to exit maintenance mode.
Is the image correct?
Enter 072 using
up/down cursor keys.
Press the system menu/counter key.
Press the enter key.
Press the enter key.
The new setting
is stored.
Setting range: -6.6 to +6.6
Initial setting: -0.7
Changing the value by 1 moves
the center line by 0.1 mm.
